Over 65W

For the greater than 65W USB-PD/PPS application, the converter can use feedback by magnetic coupling and I2C interface. The converter is a high frequency, quasi-resonant operation with GaN integrated, which can achieve high efficiency and reliability. The converter built-in high voltage start-up circuit through HV pin and X-cap discharge function. The converter VCC pin with high withstand voltage is easy to meet PD&PPS requirement with wide output voltage.

Feedback by Magnetic Coupling

DOE，excellent no load  input power

VCC high withstand voltage for extra wide output range，Meet PPS application

ESOP-10 package for cooling

140kHz high frequency QR operation

With X-cap discharge function

Primary internal LPS protection

CS resister open and short circuit protection

Internal input voltage OVP and UVP
